1930 1931 1932 1933 1934 1935 1936 1937 1938 1939 1940 1941 1942 1943 1944 1945 1946 1947 1948 1949 1950 1951 1952 1953 1954 1955 1956 1957 1958 1959 1960 1961 Cadillac Add on Under Dash Air Conditioning Kit

Free Shipping within the Continental US

Complete Air Conditioning system comes with all new parts needed for

complete AC installation.

Package includes Under Dash AC Evaporator Assembly

Compressor with Clutch, Compressor Mounting Hardware,

  Condenser and Receiver Drier,

Hoses and all Brackets, Screws, Nuts, Bolts, Washers

All parts are newly manufactured parts and come with a 1-year warranty.  System has 3 speeds and Under Dash Evaporator that measures 15.75" long x 5.28" high x 12" deep. Max Air Volume is 200 C.F.M. and Cooling Capacity is 13,700 BTU. This unit will work on any vehicle where room permits.  System will work with any approved refrigerants including R12 or 134a.

  Heat Cool upgrade available for an additional $125.00.

Compressor mounted shown in the second photo shows the drive belt going from the compressor to the generator then to the crankshaft pulley, then back to the water pump pulley. You can also use a two-belt system driving the compressor from the crankshaft pulley and water pump pulley, then use a second belt from the compressor to the generator/alternator. The compressor brackets come without holes in the plates. Installer will need to measure plates up to the engine and water pump mounting holes in the engine. Mark the plates and drill holes in the plates. Spacers, nuts, and bolts are supplied with the plates.

We build to order just for your vehicle.  You can find more on this and other systems

by contacting our Sales Team at 1-940-549-0288
